| Brand Name : | GT-Link |
| Certification : | ISO,CE,RoHS,GGS |
| Model Number : | GT-FC,SM,SX,PC |
| Price : | USD0.1~5.0/PCS |
| Delivery Time : | about 7 days once confirmed |
| Payment Terms : | T/T,CASH,Western Union etc. |
| Supply Ability : | 2000pcs/day |
Descriptioin:FC/UPC-SC/UPC SM MM Optical Fiber Pigtail/Connector
1.FC/UPC-SC/UPC SM MM Optical Fiber Pigtail/Connector
2.ROSH compliant cable,small diameter
3.high reliability & stability,OEM
Optical Fiber Patch Cord (Jumper) is a length of optical fiber with two ends adding connectors to connect beam path. Pigtail is a length of fiber permanently attached connector only at one end. Joinwit patch cords assembled with various types of connectors (such as FC, SC, ST, LC, MU, MTRJ etc.) There are three kinds of polished fiber end-face: PC, UPC and APC .we employ advanced technique and equipment to manufacture so as to ensure the high quality of mass production.
FC optical fiber patchcord
FC Stands for Fixed Connection. FC connectors are generally constructed with a metal housing
and are nickel-plated.
A pigtail is a fiber optic cable used to attached one device to another for signal routing.
Features:
Excellent mechanical endurance
High exchangeablity, credibility and stability
Cable diameter: 0.9mm, 2.0mm, 3.0mm
Ceramic(zirconia) ferrule: PC, UPC, APC optional
Cable type: PVC, LSZH, OM3, Armored
Parameter | Unit | Standard & Requirement | |||
PC(SM) | UPC(SM) | APC(SM) | PC(MM) | ||
Insertion Loss (Typical) | dB | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.3 |
Return Loss | dB | ≥45 | ≥50 | ≥60 | ≥35 |
Mechanical Endurance (500T) | dB | ≤0.2 | |||
Exchangeability | dB | ≤0.2 | |||
Durability | Time | >1000 | |||
Vibration | dB | ≤0.2 | |||
Operating Temperature | °C | -40 ~+75 | |||
Storage Temperature | °C | -45 ~+85 | |||
Cable Diameter | mm | 3.0, 2.0, 0.9 | |||
Applications:
1) CATV, metro Test equipment
2) Telecommunication networks;
3) Local area networks (LAN);
4) Wide area networks (WAN)
5) Premise installations
6) Data processing networks;
7) Video and military active device termination
